At Coltraco Ultrasonics, we specialise in cutting-edge technology designed to revolutionise how industries monitor fluid levels in tanks and pipes. Our ultrasonic liquid level indicators are reliable, accurate, and non-invasive solutions that help businesses maintain operational efficiency and safety.
Whether you are looking for a CO2 liquid level indicator, a water tank level indicator kit, or a comprehensive solution for diverse fluids, our instruments are engineered to meet the highest standards.
The Portapipe® is a portable and battery powered liquid level indicator designed to non-invasively, accurately, and reliably measure the level of liquid within a pipe. The Portapipe® can be applied to both vertical and horizontal pipes from 25mm to 330mm in diameter to provide a precise result within ±1% of true level.
P/N: 3174740-PIPE
KD983 CAGE code – COLTRACO LIMITED
The Portatank® is a versatile, handheld, portable ultrasonic liquid level indicator for fast and reliable measurements. Powered by a battery, it provides a non-invasive way to measure the liquid level within tanks, making it ideal for industrial and commercial applications.
The device can accurately measure liquid levels in vessels ranging from 0.5 meters to 15 meters in diameter. Whether working with metal, plastic, or glass tanks, the Portatank® ensures consistent results across various materials.
P/N: 3141184-TANK
KD983 CAGE code – COLTRACO LIMITED
All Coltraco ultrasonic liquid level detectors operate using advanced ultrasonic testing (UT), a reliable and versatile Non-Destructive Testing (NDT) method. The core of this system is the ultrasonic level sensor, which emits high-frequency sound waves, typically between 200 kHz and 2 MHz. These mechanical waves pass through the solid tank wall, reflecting off the internal liquid surface.
The sensor contains a piezoelectric crystal that converts electrical signals into ultrasonic pulses (the reverse piezoelectric effect). Once the pulse travels into the tank, it either reflects off the opposite wall if liquid is present or fails to return if no liquid is present.
This pulse-echo method enables accurate detection of fluid presence and levels. The device’s LED indicators signal the presence or absence of liquid.
This process does not require internal tank access, allowing for external, side-wall readings. Ultrasound gel ensures optimal signal transmission by eliminating air gaps between the sensor and the tank wall. This design ensures precise, real-time detection in diverse environments.
The Portatank® is a battery-powered, handheld ultrasonic level indicator ideal for industrial and commercial applications. It non-invasively measures liquids in tanks ranging from 0.5 to over 15 meters. Its compatibility spans various materials, including metal, plastic, and glass, irrespective of wall thickness.
Each unit includes a handheld oscilloscope for tank-specific calibration, enhancing measurement precision and diagnostic capability. Its portability means one instrument can be used across multiple tanks without installation costs, making it especially useful during maintenance or sensor replacement.
The Portapipe® is specifically designed for pipe applications. It accurately measures fluid levels in horizontal and vertical pipes with diameters between 25mm and 330mm. With a margin of error within ±1%, it delivers high accuracy for both temporary checks and routine inspections.
Our ultrasonic level detectors are widely used in the power generation sector to monitor oil levels in Single-Phase and Three-Phase transformers and RMUs. For instance, in a Yorkshire switchgear distribution box test, the Portatank® delivered readings 7cm lower than a float gauge, which were later validated by a dipstick.
Beyond oil tanks, our sensors monitor drinking water, wastewater, fuels, and chemicals. Their versatility enables application in facilities ranging from chemical plants and water treatment sites to food processing and marine environments.
Coltraco’s ultrasonic sensors provide a noninvasive solution that avoids tank modification or contamination. Because they operate externally, they eliminate downtime and support “live” testing, a critical advantage in power and fuel applications.
These sensors are primary detection tools and excellent for cross-checking built-in systems such as float level gauges, radar sensors, and sight glasses. Their ability to measure nearly all liquid types makes them highly versatile.
Each device is engineered for on-site usability. The inclusion of a handheld oscilloscope enables precise setup and real-time diagnostics. The Portatank® sensor requires only a 25 mm-wide strip of tank surface, allowing operation even in tight or obstructed installations.
Internal tank structures do not hinder performance. The ultrasound signal can still reflect off internal components, but we recommend testing near tank edges to obtain the most straightforward signal path in complex environments.
With demand rising for safe, efficient fluid-level monitoring, Coltraco’s ultrasonic liquid level detectors are leading the field. Designed to meet exacting standards, they are trusted globally across industries for their accuracy, ease of use, and robust design. Each system is manufactured in the UK and built to last.
These detectors are compatible with almost any liquid and represent a superior alternative to conventional systems. Our ultrasonic level sensors ensure continuity and safety, whether you’re managing oil, water, CO2, or chemicals.
Selecting the proper level detector means understanding your system’s specific requirements. From gauge-level devices in petroleum tanks to water-level indicator kits for potable storage, Coltraco offers tailored solutions that match your exact needs.
Our products consistently rank among the best liquid level indicators due to their technology, support, and user satisfaction. Whether you purchase from us directly or through trusted distributors, including listings like “best liquid level indicator,” you are assured of quality and reliability.
Ready to implement a high-performance liquid level detector? Contact Coltraco Ultrasonics today for expert advice and tailored recommendations. Our experienced team will help you identify the most suitable ultrasonic level sensor for your application, ensuring you receive a robust and effective solution.
Discover how our noninvasive, ultrasonic liquid level indicators can transform fluid management processes.
Experience precision, performance, and peace of mind the Coltraco way. Contact us today for more information!
